ENGPART NO. | THREAD | TUBE O.D. | DIMENSIONS | Mpa | |||
E | C | d | S2 | ||||
NL-12 | M12x1.5 | 6 | 14.5 | 6 | 14 |
L |
|
NL-14 | M14x1.5 | 8 | 14.5 | 8 | 17 | ||
NL-16 | M16x1.5 | 10 | 15.5 | 10 | 19 | ||
NL-18 | M18x1.5 | 12 | 15.5 | 12 | 22 | ||
NL-22 | M22x1.5 | 15 | 17 | 15 | 27 | ||
NL-26 | M26x1.5 | 18 | 18 | 18 | 32 | ||
NL-30 | M30x2 | 22 | 20 | 22 | 36 | ||
NL-36 | M36x2 | 28 | 21 | 28 | 41 | ||
NL-45 | M45x2 | 35 | 24 | 35 | 50 | ||
Nl-52 | M52x2 | 42 | 24 | 42 | 60 | ||
NS-14 | M14x1.5 | 6 | 16.5 | 6 | 17 |
S |
|
NS-16 | M16x1.5 | 8 | 16.5 | 8 | 19 | ||
NS-18 | M18x1.5 | 10 | 17.5 | 10 | 22 | ||
NS-20 | M20x1.5 | 12 | 17.5 | 12 | 24 | ||
NS-22 | M22x1.5 | 14 | 20.5 | 14 | 27 | ||
NS-24 | M24x1.5 | 16 | 20.5 | 16 | 30 | ||
NS-30 | M30x2 | 20 | 24 | 20 | 36 | ||
NS-36 | M36x2 | 25 | 27 | 25 | 46 | ||
NS-42 | M42x2 | 30 | 29 | 30 | 50 | ||
NS-52 | M52x2 | 38 | 32.5 | 38 | 60 |
