One Piece Hydraulic Flanges

One Piece Hydraulic Flanges

Our one-piece non-skive hydraulic flange fittings are fully CNC machined with top-quality hot forging raw materials.  Paker 43 series and Paker 71, 73 series fittings can be replaced by our one-piece fittings.
Our Cr.3 zinc plating is superb in rust resistance performance. The salt spray test result is >72 hours
We have a wide range of terminals to suit hydraulic hose 1SN, 2SN, 1SC, 2SC 4SP, 4SH, R12, R13, and R15.
Stainless steel material is available and customized design is available on request.
  • One Piece Hydraulic Flanges
  • One Piece Hydraulic Flanges
  • One Piece Hydraulic Flanges
Contact Us
  • Specification
    ATTRIBUTES DESCRIPTION
    PRODUCT NAME ONE PIECE HYDRAULIC HOSE END FITTINGS, SAE FLANGE
    PLACE OF ORIGIN CHINA
    BRAND NAME TIANXIANG
    ITEM NUMBER 87311Y(STRAIGHT), 87341Y(45 ELBOW), 87391Y(90ELBOW)
    MATERIAL CARBON STEEL 45#, OR STAINLESS STEEL
    STANDARD SAE
    SURFACE TREATMENT CR+3 ZINC or Zn-Ni
    COLOR YELLOW or WHITE
    COMPRESSION STRENGTH 3000psi
    SIZE AS PER BELOW SHEET
    PACKAGING DETAILS 60 CARTONS WRAPPED ON A WOODEN PALLET BY NYLON BELTS OR WRAPPED BY A BIG WOODEN CRATE
    CERTIFICATES ISO9001/2008
    FABRICATION TECH FORGED and CNC LATHING
    OEM SERVICE FBRICATED ACCORDING TO YOUR DRAWINGS OR SAMPLES
    LOADING PORT NINGBO/SHANGHAI
    MOQ 500pcs/ITEM FOR BIG SIZE ITEM, 2000 PCS/ITEM FOR SMALL SIZE ITEM
    LEADTIME USUALLY 25 DAYS AROUND AFTER ORDER CONFIRMATION. BUT IT DEPENDS ON ORDER VOLUME
    SUPPLY ABILITY 50000 SETS/ MONTH
